Cartridge Valve Relief T-10A, standard pressure setting 210 bar , 25 GPM

IDR 0.00 IDR 0.00

Pilot-operated, balanced-piston relief cartridges are normally closed pressure regulating valves. When the pressure at the inlet (port 1) reaches the valve setting, the valve starts to open to tank (port 2), throttling flow to regulate the pressure. These valves are accurate, have low pressure rise vs. flow, they are smooth and quiet, and are moderately fast.

  • All 2-port relief cartridges (except pilot reliefs) are physically and functionally interchangeable (same flow path, same cavity for a given frame size).

  • Will accept maximum pressure at port 2; suitable for use in cross port relief circuits. If used in cross port relief circuits, consider spool leakage.

  • Main stage orifice is protected by a 150-micron stainless steel screen.

  • Not suitable for use in load holding applications due to spool leakage.

  • Back pressure on the tank port (port 2) is directly additive to the valve setting at a 1:1 ratio.

  • Cartridges configured with EPDM seals are for use in systems with phosphate ester fluids. Exposure to petroleum based fluids, greases and lubricants will damage the seals.

  • W and Y controls (where applicable) can be specified with or without a special setting. When no special setting is specified, the valve is adjustable throughout its full range using the W or Y control. When a special setting is specified, this setting represents the maximum setting of the valve

  • Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP for external stainless steel components, or /LH for external zinc-nickel plated components. Ask Nusantara supply team for all section options.

  • For further details, please reach Nusantara Supply, find genuine Cartridge valves with expert support and global sourcing for improved system performance

Pilot-operated, balanced-piston relief cartridges are normally closed pressure regulating valves. When the pressure at the inlet (port 1) reaches the valve setting, the valve starts to open to tank (port 2), throttling flow to regulate the pressure. These valves are accurate, have low pressure rise vs. flow, they are smooth and quiet, and are moderately fast.

  • All 2-port relief cartridges (except pilot reliefs) are physically and functionally interchangeable (same flow path, same cavity for a given frame size).

  • Will accept maximum pressure at port 2; suitable for use in cross port relief circuits. If used in cross port relief circuits, consider spool leakage.

  • Main stage orifice is protected by a 150-micron stainless steel screen.

  • Not suitable for use in load holding applications due to spool leakage.

  • Back pressure on the tank port (port 2) is directly additive to the valve setting at a 1:1 ratio.

  • Cartridges configured with EPDM seals are for use in systems with phosphate ester fluids. Exposure to petroleum based fluids, greases and lubricants will damage the seals.

  • W and Y controls (where applicable) can be specified with or without a special setting. When no special setting is specified, the valve is adjustable throughout its full range using the W or Y control. When a special setting is specified, this setting represents the maximum setting of the valve

  • Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP for external stainless steel components, or /LH for external zinc-nickel plated components. Ask Nusantara supply team for all section options.

  • For further details, please reach Nusantara Supply, find genuine Cartridge valves with expert support and global sourcing for improved system performance
Flow Control Valve
Flow Control Valve
IDR 0.00 IDR 0.00

Part Number: 94520-1AN , Valve Pressure Control Relief, Matl steel , Cavity T-10A, Max 5000 psi, Max WP 3000psi,25 gpm, Standard Pressure setting 210 bar ( Main Manifold TDS 11 )

Part Number: HC01-018B-01, Valve Pressure Control pilot operated Matl Steel,, Cavity T-10A, Max 100 psi, Max2 3000psi, Max WP 1000 pai, 25 gpm, standard 70 bar ( Manifold Iron Roughneck Guide 144 Assembly )

Part Number: 3HVR00857, Valve Cartridge T-10A, Relief PLT OP Balance

Part Number: 18732836-001 , Pilot Operated Balance Piston, relief Valve, Pressure setting 210 bar

Part Number: 18732836-002 , Valve Pressure control pilot-operated Matl 316 steel, T10A conn 2, Max 205 bar Max WP 350 bar 95 gpm, pressure setting 3000 psi ( 205 bar )

Part Number : 520780, Wireline and flowline, Valve relief, Matl Steel, T-10A Cavity

Part Number: 10068523-003, Valve pressure control relief, Matl Steel T-10A Max 205 bar, Max WP 350 bar , 95 gpm, pressure setting 205 bar
